FNT75

FNT75 Specification

Model FNT75
Display Type e-Paper 7.5" Matrix
Display Active Area 163.20 x 97.92 mm
Display Resolution 640 x 384 pixel / 100 dpi
Display Color B/W, B/W/R, B/W/Y
Wireless Communication IEEE 802.15.4 Based on 2.4GHz ISM Band, Data Rate: 250Kbps, Service Area : Radius Max. 30m (Line of Sight)
Maximum Transmit Power 2.4GHz - 802.15.4 (Zigbee) 10 dBm (10mW)
Approval FCC, KC, CE
ROHS ROHS Compliance
Power Coin Battery CR2450 x 4
Battery Life 5 Years @Room Temperature (2 updates/Day)
Operating Temperature 0°C ~ 50°C / 32°F~122°F I B/W/R, B/W/Y : 5°C ~ 40°C / 41°F~104°F
Size 117.1mm x 175mm x 13.2mm
Weight 184.0g
